AVM FRITZ!BOX 55xx Fiber zbh. AON Ersatz GBIC "ALL4786-AON"

Parameter

Symbol

Min.

Max.

Unit

Supply Voltage

VCC

-0.5

3.6

V

Storage Temperature

TS

-40

85

°C

Operating Case Temperature

TC

0

70

°C

Parameter

Symbol

Min.

Typical

Max.

Unit

Operating Case Temperature

TC

0

70

°C

Power Supply Voltage

VCC

3.15

3.3

3.45

V

Power Supply Current

ICC

300

mA

Data Rate

1.25

GBps

Max Link Length on 9/125µm SMF

Lmax

20

km

Parameter

Symbol

Min.

Typical

Max.

Unit

Transmitter

Input Differential Impedance

Zin

90

100

110

Ω

Data Input Swing Differential

Vin

500

2400

mV

Tx-Dis Disable

Vd

2.0

Vcc

V

Tx-Dis Enable

Ven

0

0.8

V

TX-Fault (Fault)

2.0

Vcc+0.3

V

TX-Fault (Normal)

0

0.8

V

Receiver

Data Output Swing Differential

Vout

370

2000

mV

Rx-Los Fault

Vlf

2.0

Vcc+0.3

V

Rx-Los Normal

Vln

0

0+0.8

V

Parameter

Symbol

Min.

Typical

Max.

Unit

Transmitter

Centre Wavelength

λc

1290

1310

1330

nm

Spectral Width (RMS)

σ

4

nm

Average Output Power

Pout

-9

-3

dBm

Extinction Ratio

ER

9

dB

Optical Rise/Fall Time

tr/tf

2

ns

Receiver

Centre Wavelength

λc

1470

1490

1610

nm

Receiver Sensitivity

PIN

-23

dBm

Receiver Overload

PMAX

-3

dBm

LOS De-Assert

LOSD

-30

dBm

LOS Assert

LOSA

-35

dBm

LOS Hysteresis

0.5

4.5

dB

Pin

Symbol

Description

Ref.

1

VEET

Transmitter Ground (Common with Receiver Ground)

6.1

2

TFAULT

Transmitter Fault. Not supported.

3

TDIS

Transmitter Disable. Laser output disabled on high or open.

6.2

4

MOD_DEF(2)

Module Definition 2. Data line for Serial ID.

6.3

5

MOD_DEF(1)

Module Definition 1. Clock line for Serial ID.

6.3

6

MOD_DEF(0)

Module Definition 0. Grounded within the module.

6.3

7

Rate Select

No connection required

8

LOS

Loss of Signal indication. Logic 0 indicates normal

operation.

6.4

9

VEER

Receiver Ground (Common with Transmitter Ground)

6.1

10

VEER

Receiver Ground (Common with Transmitter Ground)

6.1

11

VEER

Receiver Ground (Common with Transmitter Ground)

6.1

12

RD-

Receiver Inverted DATA out. AC Coupled.

13

RD+

Receiver Non-inverted DATA out. AC Coupled.

14

VEER

Receiver Ground (Common with Transmitter Ground)

6.1

15

VCCR

Receiver Power Supply

16

VCCT

Transmitter Power Supply

17

VEET

Transmitter Ground (Common with Receiver Ground)

6.1

18

TD+

Transmitter Non-Inverted DATA in. AC Coupled.

19

TD-

Transmitter Inverted DATA in. AC Coupled.

20

VEET

Transmitter Ground (Common with Receiver Ground)

6.1
