Netzwerkkarten - Kupfer

Highlights: Erweitern Sie ihr Laptop oder Tablet über eine USB 3.0-Anschluss um eine Netzwerk Gigabit Schnittstelle.  Native Treiberunterstützung (Windows, Mac und Chrome OS) durch integrierten Realtek RTL8153 Chipset Bietet zuverlässigen kabelgebundenen Netzwerkzugang mit einem 10/100/1000 RJ45 Ethernet-Anschluss, der mit IEEE kompatibel ist USB-betrieben für einfache Portabilität Automatische MDIX-Unterstützung & Unterstützung von Vollduplex-Flusssteuerung VLAN Konfiguration möglich mit Boardmitteln oder mit Realtek Software Unterstütztes Betriebssystem: Windows 7, 8, 8.1, 10 | Mac OS X 10.7 bis 10.15 | Linux Kernel 2.6.25 bis 4.11.x Nur LTS-Versionen Erhalten Sie schnellen, zuverlässigen Netzwerkzugang für Ihr MacBook, Chromebook™ oder Tablet, auch wenn es keinen Ethernet-Anschluss hat. Dieser USB 3.0-zu-Gigabit-Netzwerkadapter fügt Ihrem Computer über Ihren USB 3.0-Anschluss einen einzigen RJ45-Ethernet-Anschluss hinzu. Er lässt sich sofort installieren - ohne dass ein Treiber erforderlich ist. Dieser kompakte und tragbare USB-Netzwerkadapter ist das ideale Laptop-Zubehör. Sie müssen keinen Stromadapter bei sich tragen, um ihn zu verwenden, da er direkt über den USB-Host-Anschluss mit Strom versorgt wird. Der USB 3.0-Netzwerkadapter ist ideal für den Einsatz im Büro oder zu Hause und unterstützt die volle Gigabit-Bandbreite, indem er die Leistung von USB 3.0 (5 Gbit/s) nutzt. Sie können über ein Gigabit-Netzwerk schnell auf sehr große Dateien zugreifen und so jeden Tag wertvolle Zeit sparen. Der Realtek-Chipsatz gibt Ihnen die Gewissheit einer zuverlässigen Leistung. Schnell einsatzbereit. Schließen Sie diesen Ethernet-Kabeladapter einfach an den USB-Port Ihres Laptops an und verbinden Sie ihn mit Ihrem Netzwerk. Der Netzwerkadapter-Chipsatz bietet native Treiberunterstützung, so dass Sie sich nicht um die Installation zusätzlicher Software kümmern müssen. Technical Details: Category Element Spezifikation Connector(s) Connector Type(s) 1 - USB Type-A (9 pin) USB 3.0 (5 Gbps) 1 - RJ-45 Environmental Operating Temperature 0°C to 70°C (32°F to 158°F) Storage Temperature -55°C to 125°C (-67°F to 257°F) Humidity 20% ~ 90% Hardware Ports 1 Interface USB 3.0 Bus Type USB 3.0 Industry Standards IEEE 802.3 10BASE-T, IEEE 802.3ab 1000BASE-T, IEEE 802.3u 100BASE-TX and IEEE 802.3X Full Duplex Chipset ID Realtek - RTL8153 Indicators LED Indicators 1 - Power - blue 1 - Link - green 1 - Activity - amber Packaging Information Package Dimmension     Shipping (Package) Weight   Performance Maximum Data Transfer Rate 1 Gbps - Full Duplex Gigabit Ethernet   Max Distance 100 m / 330 ft   Type and Rate USB 3.0 - 5 Gbit/s   Surge Protection Yes   Compatible Networks 10/100/1000 Mbps   Auto MDIX Yes   Full Duplex Support Yes Physical Characteristics Form Factor Attached Cable   Weight of Product     Color Black   Material Plastic   Cable Length     Product Dimmension   Software OS Compatibility Windows® 7, 8, 8.1, 10 Mac OS X® 10.7 to 10.15 Linux Kernel 2.6.25 to 4.11.x LTS Versions only Chrome OS® What's in the Box Included in Package 1 - USB 3.0 Gigabit NIC

Die kompakte Netzwerkkarte mit integriertem Ladeport. Der ALL-NC-1GPD-USB-C ist ein kompakter Gigabit Netzwerkadapter für Stationären oder Mobilen Einsatz mit USB-C-Schnittstelle. Der integrierte PD USB-TypeC Ladeport ist vorgesehen das sie Ihr Endgerät sowohl mit einer Netzwerkkarte ausstatten als auch gleichzeitiges Laden mit max. Leistung von 100W. Der ALL-NC1GPD-USB-C ist in ein kompaktes Metallgehäuse gebettet welches für die 100W Ladeleistung benötigt wird. Die Kabel Ein & Ausgänge sind verstärkt damit Sie nicht leicht knicken können. Der mitgelieferte Adapter von USB Type C-Eingang auf USB-Type-A ermöglicht das sie den ALL-NC-1GPD-USB-C nicht nur an USB-C sondern auch an USB-A Endgeräten betreiben können. Der ASIX 88179A USB Chipset wird von allen gängigen Betriebssystemen automatisch erkannt und somit Plug and Play. • Chipsatz: ASIX 88179A USB 3.2 Gen1 to Gigabit • Anschlüsse:     1 x USB 3.0 Typ C Stecker     1 x Gigabit LAN RJ45 Buchse     1x PD Type C Buchse mit max. 100W Ladeleistung • Datentransferraten:     Ethernet bis zu 10 Mb/s (Half/Full Duplex)     Fast Ethernet bis zu 100 Mb/s (Half/Full Duplex)     Gigabit bis zu 1000 Mb/s (Half/Full Duplex)      • Unterstützt Auto MDIX (automatische Erkennung von Standard oder Crossover Netzwerkkabel) • Windows Vista, 8, 10, 11, Mac OS, Linux kompatibel und Treiber verfügbar • PC oder Notebook mit einem freien USB 3.0 oder USB 2.0 Port     • Unterstützt Wake on Lan !! Merkmale - USB-Typ-A-zu-RJ45-Adapter unterstützt 1-Gigabit-Netzwerke über USB 3.2 Gen1 - Kompatibel mit IEEE 802.3i, 802.3u und 802.3ab (10BASE-T, 100BASE-TX und 1000BASE-T) - Stromversorgung direkt über die USB-Anschlüsse - Integrierter PD USB Type C Buchse mit max. Ladeleistung von 100W. Somit haben Sie die Möglichkeit sowohl Netzwerk als auch gleichzeitiges Laden bis zu 100W am gleichen Port. Kein Portverlust. - Kompakte, leichte Konstruktion für maximale Tragbarkeit

Der kompakte Super-Speed ALL-NC-2.5G-USBC/A-Adapter bietet eine nahtlose Umwandlung des USB-C 3.1 Gen 1-Ports in einen leistungsstarken Gigabit Ethernet 10/100/1000/2500 Mbps-Port. Neben einer beeindruckenden Bandbreite von 2,5 Gigabit präsentiert diese Netzwerkkarte eine breite Palette an Funktionen. Dazu zählen unter anderem die IPv4/IPv6-Prüfsummen, welche die CPU-Belastung reduzieren, die automatische Crossover-Erkennung und -Korrektur, die Möglichkeit des TCP Large Send Offload, vielfältige Modi zur Unterstützung von Wake-on-LAN-Funktionen, die Integration mit virtuellen LANs (VLANs) sowie erweiterte Power-Management-Funktionen. Der Adapter ermöglicht eine mühelose, automatische Installation in modernen Betriebssystemen ab Windows 8.1, ohne dass eine aktive Internetverbindung erforderlich ist. Diese Gigabit-Netzwerkkarte erweitert die Netzwerkfähigkeiten Ihres Computers erheblich. Sie ergänzt fehlende RJ-45-Netzwerkanschlüsse oder andere Netzwerkkarten und ersetzt sogar veraltete oder nicht mehr funktionierende Netzwerkverbindungen. Mit Unterstützung für die neuesten Versionen von Windows, Mac OS X und Linux-Betriebssystemen ist diese Karte für jeden Desktop, Laptop oder Ultrabook geeignet, der über einen zeitgemäßen, beidseitigen USB-Typ-C-Anschluss verfügt. Der USB-C-Stecker der Netzwerkkarte ist zusätzlich mit einem Adapter von USB-A auf USB-C ausgestattet. Dadurch haben Sie die Flexibilität, die Netzwerkkarte sowohl an einem USB Type-C- als auch an einem USB Type-A-Anschluss zu verwenden. Technical Details: Input: Interface USB 3.1 gen 1 / USB 3.0, backward compatible with USB 2.0 and USB 1.1. Connecting USB Type C male connector on a 30 cm long cable permanently attached to the adapter Output: 2.5 Gigabit Ethernet interface with RJ-45 connector for UTP or STP cable connection. Supported transmission rates for the Ethernet interface 10/100/1000/2500 Mb/s. Supported IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T specifications. 10/100/1000 Mbit/s auto-detection. Supports IPv4 / IPv6 packet Checksum Offload Engine (COE) to reduce processor load, including IPv4 IP/TCP/UDP/ICMP/ IGMP & IPv6 TCP/UDP/ICMPv6 checksum control and generation. Supports TCP Large Send Offload V1 and V2. Supports IEEE 802.1P Layer 2 priority encoding & decoding. Supports IEEE 802.1Q VLAN tagging. Supports IEEE 802.3az EEE (Energy Efficient Ethernet) - reduce power consumption at rest. Supports Jumbo frame. Supports full-duplex transmissions with IEEE 802.3x flow control and half-duplex transmissions with back-pressure flow control. Supports Auto MDI/MDIX - crossover detection and auto-correction eliminates the need for crossover cables. Other features: Full Plug and Play and Hot Plug support. Supports CDC-ECM – for automatic installation of drivers across different OSs. Adapter power supply via USB (bus power) - no auxiliary power supply required. Three LEDs: Green - Network link / Yellow - Data Activity / White - Power. Dimensions 61 x 23 x 17 mm, USB cable length 30 cm. Supports Wake-on-LAN feature in different modes: Supports sleep mode and remote Wake Up via Magic Packet, Microsoft Wakeup Frame, Microsoft Wake Packet Detection and Link Change Wake-up. Supports ECMA-393 proxZzzy® standard for sleeping hosts to manage the network connection of sleeping guests using proxy servers. RealWoW! technology support allows remote wake up over the Internet. Supported OSs: MS Windows XP / Vista / 7 / 8 / 8.1 / 10 and later, Windows Server 2003 / 2008 / 2012 / 2016 and later (supported are all 32 and 64-bit versions of Windows OSs), MacOS X 10.6 and higher, Linux with kernel 2.6.14 and above, Android most versions (WARNING - check with the Android device manufacturer if the Ethernet connection is supported).

ALLNET ALL-NC-2G-102-USB-A USB 3.0 auf Dual Port Gigabit Ethernet Adapter NIC mit USB-Anschluss - Fügen Sie Ihrem Laptop zwei Gigabit-Ethernet-Ports und einen USB 3.0-Pass-Through-Port über einen einzigen USB 3.0-Port hinzu. Mit dem USB 3.0 auf Dual Port Gigabit Ethernet Adapter können Sie zwei Gigabit Ethernet Ports über einen einzigen USB 3.0 Port an Ihren Laptop oder Ultrabook™ Computer anschließen. Jeder RJ45-Port unterstützt 10/100/1000 Mbps Ethernet und ist voll kompatibel mit IEEE 802.3i/u/ab Standards. Dieser 2-Port-USB-LAN-Adapter ist eine vielseitige Lösung für den gleichzeitigen Anschluss an zwei getrennte physische Netzwerke und nutzt die 5-Gbit/s-Geschwindigkeit von USB 3.0, um jedem Port eine dedizierte Gigabit-Bandbreite zur Verfügung zu stellen. Die Dual-USB-Netzwerkkarte ist auch ideal für die Bereitstellung von dedizierten physischen Netzwerkschnittstellen für virtuelle Maschinenkonfigurationen. Ideal für IT-Administratoren, die Dual-Homed- oder Multi-Homed-Host-Systeme benötigen. Das USB 3.0 NIC unterstützt IPv4/IPv6 Paket Checksum Offload Engine (COE) und TCP Large Send Offload, um die CPU zu entlasten, sowie Jumbo Frames, Vollduplex-Betrieb mit 802.3x Flow Control und VLAN-Tagging für einen effizienten und vollwertigen USB-Netzwerkadapter. Anwendungen Business- oder IT-Fachleute, die sich gleichzeitig mit zwei getrennten Netzwerken verbinden müssen Führen Sie eine oder mehrere virtuelle Maschinen auf einer Workstation mit Zugriff auf separate physische Netzwerkverbindungen aus. Ersatz für einen defekten eingebauten Gigabit-Ethernet-Port auf einem Laptop Eigenschaft Duale Gigabit-Ethernet-Ports über eine einzige USB-Verbindung Integrierter USB 3.0-Pass-Through-Anschluss IEEE 802.3, 802.3u und 802.3ab (10BASE-T, 100BASE-TX und 1000BASE-T) kompatibel Frequenzweichenerkennung & Auto-Korrektur (Auto MDIX) IEEE 802.1Q VLAN Tagging Unterstützung Bis zu 4K Jumbo Frame Unterstützung Unterstützt Checksummen-Offload (IPv4, IPv6, TCP, UDP) und Large Send Offload Kompaktes, leichtes Design für maximale Mobilität   Technische Daten:   Information Hardware Bus Type USB 3.0 Chipset ID ASIX - AX88179 (2) VIA - VL811 Industry Standards IEEE802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az Interface RJ45 (Gigabit Ethernet) Ports 2 Performance Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Full Duplex Support Yes Jumbo Frame Support 4K max. Max Distance 100 m / 330 ft Maximum Data Transfer Rate 5 Gbps (USB 3.0) 2 Gbps (Ethernet - Full-Duplex) Type and Rate USB 3.0 - 5 Gbit/s Connector(s) Connector Type(s) 1 - USB Type-A (9 pin) USB 3.0 Female   1 - USB Type-A (9 pin) USB 3.0 Male   2 - RJ-45 Female Software OS Compatibility Windows® XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS® 10.6 to 10.12 - VLAN tagging is currently not supported in Mac OS Linux Kernel 2.6.25 to 4.11.x LTS Versions only Special Notes / Requirements System and Cable Requirements Available USB port Indicators LED Indicators 1 - Gigabit Link/Activity (Amber)   2 - 10/100 Link/Activity (Green) Power Power Source USB-Powered Environmental Humidity 5~85% RH Operating Temperature 0°C to 50°C (32°F to 122°F) Storage Temperature -20°C to 60°C (-4°F to 140°F) Physical Characteristics Cable Length   Color Black Enclosure Type Plastic Form Factor Attached Cable Product Height   Product Length   Product Weight   Product Width   Packaging Information Shipping (Package) Weight   What's in the Box Included in Package 1 - USB 3.0 Dual Network Adapter   1 - Driver CD   1 - Instruction Manual

Technical Details:   LAN-Standard Fast Ethernet Bus PCI 32 Bit LAN-Controller Realtek 8139D Wake-on-LAN: Yes BootROM-Socket: Yes LED-Indicators: 2x LED Standards/Specifications IEEE 802.3u; IEEE 802.3; PCI 2.1   LAN-CONNECTIONS: 1x RJ45   TRANSFER RATE: 10 Mbps 10BaseT 100 Mbps 100BaseTX Full-duplex: Yes   POWER SUPPLY: Bus-Powered: Yes   SOFTWARE: Driver Windows; NetWare; UNIX; Linux; Mac OS   GENERAL DATA: Mark: FCC; CE     SUPPLIED: Packaging Retail Manual   FEATURES: NWay Auto-Negotiation Data Transfer Mode Busmaster

Highlights: The PCIe x4 AQC107S 10GbE Ethernet card is a high-performance, multi-gigabit Ethernet card that supports the 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-T, the AQtion Ethernet controller easily handles the 10GbE Line-rate performance.  The AQC107 incorporates Aquantia’s AQrate PHY technology which delivers 10GbE network connectivity speed through Cat 6a, and delivers 5 GbE and 2.5 GbE network connectivity speed through 100 meters of Cat 5e or better cabling enabling higher data rates with zero change to legacy cabling. FEATURES - Compliant with PCIE Express Revision 3.0 and downstream with PCI Express Reivison 2.0 - Supports line rate of 8.0GT/s and 5.0GT/s per lane - Supports communication and management function - Integrated Aquantia AQrate PHY featuring NBASE-T technology - Supports PHY specifications with 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T /100BASE-T. - On-chip high resolution cable analyzer for advanced cable diagnostics - Energy Efficient Ethernet (EEE) Support - Supports IEEE1588v2 Precision Time Protocol - Support large send offload, Receive Side Scaling (RSS), Direct Cache Access (DCA) and Header checksum for increased network performance and lower host CPU utilization - Supports IPv4, IPv6 and IPv6/UDP checksum offload - Supports Jumbo frame (up to 16kbytes) - Quality of Service (QoS) - Supports up to eight traffic classes and Data Center Bridging (DCB) Target Applications - Marvell AQtion power leading -edge solutions for motherboards, PCs, Workstations, docking station, NAS, Router, Gateways and other embedded applications System Requirements - Drivers: Windows 10/8.1/8/7, Linux 3.10 and higher - Utilities: ROM programming and Windows Installer - Boot Options: UEFI and PXE Technical Details: Essentials Product Collection Network 10G mGig Controller Processors Marvell AQC107S Bus Type PCI Express Gen 3x2 or Gen 2x2 Data Rate 5-Speeds: 10G/5G/2.5G/1G/100M  Media Copper 100 meters over Cat 6a at 10Gbps 100 meters over Cat 5e (or better) at 5Gbps/2.5Gbps/1Gbps/ 100Mbps (requires no change to existing infrastructure or cabling) Boot Options UEFI and PXE Bracket Full-height bracket installed. Low-profile bracket included in package Dimension 79 mm x 68 mm (PCIe Board) Technical Specifications Network protocol IEEE802.3an, IEEE802.3bz, IEEE802.3ae, IEEE1588v2, IEEE802.3ab, IEEE802.3z, IEEE802.3u Jumbo frames 16Kbytes IPv4/IPv6 Flow Control Support Boot Options UEFI and PXE System Requirements Windows Client Windows 10/ 8.1/ 8/ 7, Windows Sever 2012/ 2012 R2/ 2016/ 2019 Apple device Mac OS  Linux Client Linux kernel: 2.6.32/3.x/4.x or higher, Linux CentOS/RHEL6.5/7.X or higher, Ubuntu: 14.x/15.x/16.x or higher, VMware: ESX/ESXi 4.x/5.x/6.x or higher Environment & Certification Power Consumption Max. 3.8W at 10Gbps, 3.0W at 5Gbps Storage Humidity Maximum 90% non-condensing relative humidity at 35 °C Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F) Operating Temperature 0 °C to 55 °C (32 °F to 131 °F) LED Indicators LINK (solid) and ACTIVITY (blinking) LINK S PEED ( green=10 G bps; yellow=1 G bps) Marks CE FCC RoHS

Dual- and Quad-port Gigabit Ethernet server adapters designed with performance enhancing features and new power management technologies Overview The ALL0136v2-4-GB-TX Intel Ethernet Server Adapter I350 family, these adapters represent the next step in the Gigabit Ethernet (GbE) networking evolution for the enterprise and data center by introducing new levels of performance through industry-leading enhancements for both virtualized and iSCSI Unified Networking environments. This new family of adapters also includes new power management technologies such as Energy Efficient Ethernet (EEE) and DMA Coalescing (DMAC). Key Features -- Dual - or Quad -port Gigabit Ethernet adapters with copper or fiber interface options -- Innovative power management features including Energy Efficient Ethernet (EEE) and DMA Coalescing for increased efficiency and reduced power consumption -- Flexible I/O virtualization for port partitioning and quality of service (QoS) of up to 32 virtual ports -- Scalable iSCSI performance delivering cost-effective SAN connectivity -- High-performing bridgeless design supporting PCI Express* Gen 2.1 5GT/s -- Reliable and proven Gigabit Ethernet technology from Intel Corporation   Essentials Product Collection Intel I350 Ethernet Server Adapter  Controller Processors Intel NHI350AM4 Bus Type/Bus Width PCI Express* 2.1 (5 GT/s) x4-lane, operable in x4, x8 and x16 slot Connections 4 x RJ-45 (Copper) Data Rate Supported 10/100/1000 Mbps (Copper), 1000 Mbps (Fiber) Cable Distances Copper: up to 100 m Category-3 or higher for 10BASE-T operation Category-5 or higher for 100BASE-TX operation Category-5e or higher for 1000BASE-T operation Fiber: MMF 62.5/50 um Bracket Full-height bracket installed. Low-profile bracket included in package Dimension 130 mm x 69 mm (PCIe Board) Technical Specifications IEEE standard Network topology IEEE 802.3/10BASE-T, 100BASE-TX, 1000BASE-T IEEE* 802.3 Auto-negotiation 1Gb/s Ethernet IEEE 802.3, 802.3u, 802.3ab PHY specifications Compliant Integrated PHY for 10/100/1000 Mb/s for multispeed, fulland half-duplex IEEE 802.3x and 802.3z compliant flow control support with software-controllable Rx thresholds and Tx pause frames Automatic cross-over detection function (MDI/MDI-X) IEEE 1588 protocol and 802.1AS implementation ? Interrupt Levels INTA, INTB, INTC, INTD, MSI, MSI-X System Requirements Windows Client Windows 11/ 10/ 8.1/ 8/ 7 Windows Sever 2008 R2/ 2012/ 2012 R2/ 2016/ 2019/ 2022 Linux RHEL7.9/ 8.4/ 8.5, SLES12SP5, SLES15SP3, Ubuntu18.04LTS/ 20.04LTS, FreeBSD 12.2/ 13 Environment & Certification Power consumption (typical) Copper: I350T2V2 4.4 W I350T4V2 5.0 W Fiber: I350F2 5.5 W I350F4 6.0 W Storage Humidity Maximum 90% non-condensing relative humidity at 35 °C Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F) Operating Temperature 0 °C to 55 °C (32 °F to 131 °F) Connect Speed LED Indicators Not illuminated=10 Mb/s; green=100 Mb/s; amber=1 Gb/s (Copper) ? Green=1 Gb/s. Not illuminated=no link (Fiber) Certifications CE FCC RoHS

Kabel USB, C(St) => RJ45(St)_Netzwerkkarte,  3.0m, USB3.2 Type-C,  schwarz(Textil), Synergy 21, Kabeltyp USB3.2(geschirmt, PVC mit Baumwollgeflecht) Kategorie AWG28 Anschluss Seite A Typ C(Stecker) Anschluss Seite B RJ45(Stecker) Kabellänge 3 m Kabelfarbe Schwarz Besonderheit Kabel in Synergy21 Blisterverpackung Außendurchmesser 4,8mm Netzwerkgeschwindigkeit 10/100/1000Mbps

Heben Sie Ihre Endgeräte auf die nächste Geschwindigkeitsstufe. Native Treiberunterstützung macht die Installation sehr einfach. Schließen Sie einfach diesen USB-X-zu-Ethernet-Adapter an den USB-Port Ihres Laptops an und verbinden Sie ihn mit Ihrem Netzwerk. Der Realtek RTL8156-Chipsatz des Netzwerkadapters bietet native Treiberunterstützung für Mac OS und Linux. Alle Windows-Betriebssysteme ohne den Treiber werden automatisch aufgefordert, die Software direkt vom Adapter herunter zu laden, so dass eine schnelle Installation ohne Internet-Zugang gewährleistet ist. • Chipsatz: RTL8156X • Anschlüsse:     1 x USB 3.0 Typ A Stecker     1 x 2.5Gigabit LAN RJ45 Buchse • Datentransferraten:     Ethernet bis zu 10 Mb/s (Half/Full Duplex)     Fast Ethernet bis zu 100 Mb/s (Half/Full Duplex)     Gigabit bis zu 1000 Mb/s (Half/Full Duplex)     MultiGigabit bis zu 2500 Mb/s (Half/Full Duplex) • Unterstützt Auto MDIX (automatische Erkennung von Standard oder Crossover Netzwerkkabel) • Windows Vista, 8, 10, Mac OS, Linux kompatibel und Treiber verfügbar • PC oder Notebook mit einem freien USB 3.0 oder USB 2.0 Port     • Unterstützt WOL-Wake on Lan !! Merkmale - USB-Typ-A-zu-RJ45-Adapter unterstützt 2,5-Gigabit-Netzwerke überUSB 3.0 - IEEE 802.3bz (2,5GBASE-T)-kompatibel - Kompatibel mit IEEE 802.3i, 802.3u und 802.3ab (10BASE-T, 100BASE-TX und 1000BASE-T) - Stromversorgung direkt über die USB-Anschlüsse - Unterstützung von IEEE 802.1Q VLAN-Tagging - Jumbo Frame-Unterstützung bis zu 16K   Hinweis 1: Für Linux und OSX wird die USB-SetConfig vom USB-Framework des Systems (USB-Host-Controller-Treiber und/oder USB-Bus-Treiber) verwaltet; dieses Verhalten kann dazu führen, dass der 2.5G-Ethernet-Adapter nicht in den automatischen Installationsmodus wechselt. Infolgedessen unterstützt der 2,5G-Ethernet-Adapter den Auto-Installationsmodus nur unter Windows. Für Linux unterstützt der 2.5G-Ethernet-Adapter einen integrierten In-House/ECM/NCM-Treiber. Für OSX unterstützt der 2.5G-Ethernet-Adapter einen integrierten ECM/NCM-Treiber; Benutzer können auch einen Inhouse-Treiber installieren. Anmerkung 2: Microsoft Wake Packet Detection (WPD) zur Bereitstellung von Wake-Up Frame-Informationen für das Betriebssystem, z.B. PatternID, OriginalPacketSize, SavedPacketSize, SavedPacketOffset, usw. WPD hilft, das unerwünschte/unautorisierte Aufwecken eines schlafenden Computers zu verhindern. Einzelheiten finden Sie in der Schnittstellenspezifikation für die Microsoft Wake Packet Detection (WPD) (http://msdn.microsoft.com/en- us/library/hh440160(v=vs.85).aspx). Anmerkung 3: 'RealWoW! (Wake - On - WAN) Technologie ermöglicht es dem 2.5G Ethernet-Adapter, keep-alive-Pakete an den Wake-Server zu senden, wenn sich der PC im Ruhezustand befindet. RealWoW! kann Wake-up-Pakete durch ein NAT-Gerät (Network Address Translation) leiten. Diese Funktion ermöglicht es PCs, den Stromverbrauch zu reduzieren, indem sie bis zu ihrer Verwendung im energiesparenden Ruhezustand bleiben. Benutzer können sich über das Internet in den Wake-Server einloggen, um den ausgewählten schlafenden PC zu wecken.  Bei der ersten Benutzung ist die Registrierung der Kontoinformationen auf dem Wake-Server erforderlich.

Hightlights: Chipset: Intel JL82576EB PCIExpress host interface specification v2.0 with 2.5GT/s BUS width PCIExpress lanes: x4  MDI (Copper) standard IEEE 802.3 Ethernet interface for 1000BASET, 100BASETX, and 10BASET applications (802.3, 802.3u, and 802.3ab) SerializerDeserializer (SERDES) to support 1000BaseSX/X/LX (optical fiber) for Gigabit backplane applications. Layer 2 functions: IEEE 802.3x Flow Control IEEE 802.1q VLAN Supports Receiveside scaling (RSS) Supports IPv 4, IPv 6 protocols Supports Jumbo Frames up to 9.5K Supports UDP.TCP and IP Checksum offloading  Statistics for management and RMON Support for virtual machines device queues Queues per port: 16 TX queues and 16 RX queues FullSpectrum Security Next Generation VMDq Support (8VMs) Interrupt throttling control to limit maximum interrupt rate and improve CPU usage The PCIe* v2.0 (2.5GT/s) Intel 82576 GbE Network adapter is a single, compact, low power component that offers two fully integrated Gigabit Ethernet Media Access Control (MAC) and physical layer (PHY) ports.  The 82576 enables two port implementation in a relatively small area and can be used for server system configurations such as rack mounted or pedestal servers, where the 82576 can be used as addon NIC or LAN on Motherboard (LOM) design.  Another system configuration is blade servers, where it can be used as LOM. The 82576 can also be used in embedded applications such as switch addon cards and network appliances. Technical Details: Essentials Product Collection Intel GbE Ethernet Server Adapter  Controller Processors Intel JL82576EB Bus Type/Bus Width PCI Express* 2.0 (2.5 GT/s) x4-lane, operable in x4, x8 and x16 slot Connections 2 x RJ45 Copper Data Rate Supported 10/100/1000 Mbps (Copper) Cable Distances Copper: up to 100 m Category-3 or higher for 10BASE-T operation Category-5 or higher for 100BASE-TX operation Category-5e or higher for 1000BASE-T operation Bracket Full-height bracket installed. Low-profile bracket included in package Dimension 113 mm x 69 mm (PCIe Board) Technical Specifications   IEEE standard/Network topology MDI (Copper) standard IEEE 802.3 Ethernet interface for 1000BASE-T, 100BASE-TX, and 10BASE-T applications (802.3, 802.3u, and 802.3ab) Interrupt Levels INTA, INTB, INTC, INTD, MSI, MSI-X System Requirements   Windows Client Windows 10/ 8.1/ 8/ 7 Windows Server 2008 R2/ 2012/ 2012 R2/ 2016/ 2019 Linux RHEL7.9/ 8.4/ 8.5, SLES12SP5, SLES15SP3, Ubuntu18.04LTS/ 20.04LTS, FreeBSD 12.2/ 13 Environment & Certification Storage Humidity Maximum 90% non-condensing relative humidity at 35 °C Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F) Operating Temperature 0 °C to 55 °C (32 °F to 131 °F) Connect Speed LED Indicators Not illuminated=10 Mb/s; green=100 Mb/s; amber=1 Gb/s (Copper) Marks CE   FCC   RoHS

Highlights: Single Port 10/100/1000Mbps adapter PCI Express v1.1 x1 lane RJ45 Connectivity Low-cost, low-power VLAN Support Innovative power management features MSI,MSI-X support Excellent small packet performance for network appliances Low profile and full-height bracket Overview: ALL0142-1G-DTX  is a PCI Express v1.1 x1 manageable Gigabit RJ45 Single Port Network Card.The Card contains two transmit and two receive queues for the single port. It has advanced interrupt-handling,IPv4 and IPv6 checksum offload,TCP/UDP checksum offload features and the Auto-Negotiation (Nway) function ,Jumbo Frame support.With single UTP/STP and the Auto-Negotiation (Nway) function support, the Card can auto-negotiate 10Mbps, 100Mbps or 1000Mbps speed, and half or full duplex mode with its link partner (a hub, for example). Supports ACPI, compliant with PCI Express2.1. Full range of drivers are provided for major Operating Systems. Technical Details: Controller Intel I211 Transmission rate per port 10/100/1000Mbps Network Standard Physical Layer Interfaces 1000BASE-T:Cat 5eor higherup to 100m 100BASE-Tx:Cat5/5e/6or higherup to 100m 10BASE-T: Cat3/4/5/5e/6or higherup to 100m Jumbo Frame Support Up to 9.5 KB Operating Temperature 0 °C to 55 °C (32 °F to 131 °F) Network Virtualization LED Indicators 1000Mbps/s:Yellow Link and Green Ack, 100Mbps/s:Green Link and Green Ack,10Mbps/s: Not illuminate Operating System Support Windows Server2008 / 2008 R2 / 2012 /2012 R2 /2016 R2 Windows 7 / 8 / 8.1 / 10 Linux Stable Kernel version 2.6.x / 3.x / 4.x or later Linux SLES 10 / 11 or later VMvare ESX/ESXi 5.x/6.x or later

Description: ALLNET ALL0137-1-40G-QSFP+ 40 Gigabit Ethernet PCI Express server adapter is designed for Servers and high-end appliances. ALL0137-1-40G-QSFP+ offer simple integration into any PCI Express X8 to 40Gigabit Networks. The performance is optimized so that system I/O is not the bottleneck in high-performance networking applications.   ALLNET ALL0137-1-40G-QSFP+ is based on Intel XL710AM1 Ethernet controller with two fully integrated Gigabit Ethernet Media Access Control (MAC) and XLPPI Interface. In addition to managing MAC and PHY Ethernet layer functions, the controller manages PCI Express packet traffic across its transaction, link, and physical/logical layers. Using hardware acceleration, the controller offloads tasks from the host, such as TCP/UDP/IP checksum calculations and TCP segmentation. ALLNET ALL0137-1-40G-QSFP+ is the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers.   Key Features: Performance Features: Support for jumbo frame up to 9.5KB Flow control support Priority Flow Control (draft IEEE 802.1Qbb) Enhanced Transmission Selection (draft IEEE802.1az) Statistics management and RMON 802.1q VLAN support DCB/DCB-X support Message Signal interrupts (MSI-X) Storage - Enabling competitive performance with native OS intelligent offload solutions, including NAS, iSCSI and FcoE   Host Interface: PCI Express X8 lanes Support PCI Express Base Specification 3.0 (8GT/sec)   LAN and Virtualization Features: Network Virtualization offloads for VXLAN and NVGRE Unified Networking Providing a single wire for LAN and storage: NAS (SMB, NFS) and SAN (iSCSI,FCoE) Virtual Bridging Support – VEPA/802.1Qbg, BPE/802.1Qbh Physical Functions – Up to 8 per port, up to 16 per device Support for 128 Virtual Device Queues (VMDq) per port Hardware Queue Pairs – Up to 1.5K (non-RDMA); up to 256K (RDMA) Virtualization - Alleviating hypervisor I/O bottlenecks by providing flow separation for Virtual Machines (VMs)   TCP/IP/L2 features: Receive Side Scaling (RSS) Large Send Offload (LSO) TCP/UDP/IP/SCTP Checksum Offload IPV4, IPV6   Technical Details: QSFP+ 40Gigabit Ethernet Technical Specifications Adapter: QSFP+ (Quad Small Formfactor Pluggable) supports: XLPPI interfaces supports 40GBase-R PCS and 40 Gigabit PMA in order to connect with QSFP+ to 40GBase-SR4 / 40GBase-LR4 / 40G Direct Attach Cable IEEE Standard /Network topology: with 40GBase-SR4 QSFP+ Fiber 40Gigabit Ethernet, 40GBASE-SR4 (850nm LAN PHY). IEEE Standard /Network topology: with 40GBase-LR4 QSFP+ Fiber 40Gigabit Ethernet, 40GBASE-LR4 (1310nm LAN PHY) Operating Systems Support Operating system support: Windows Linux General Technical Specifications Interface Standard: PCI-Express Base Specification Revision 3.0 (8 GT/sec) Board Size: 165mm X 69mm(6.496 X 2.717) PCB thickness is 0.062 inch PCI Express Card Type: X8 Lane PCI Express Voltage +12V +- 8% PCI Connector: X8 Lane Controller: Intel XL710AM1 Holder: Metal Bracket Weight: 130gr (4.568 oz) Power Consumption 3.600W Operating Humidity: 0%–90%, non-condensing Operating Temperature: 0°C – 45°C (32°F – 113°F) Storage: -40°C–65°C (-40°F–149°F) EMC Certifications: FCC PART 15B EN 55022: 2010 EN 55024: 2010 EN 61000-3-2:2014 EN 61000-3-3:2013 LEDs LEDs: Link 10G :Green Link 40G: Yellow Act: Blue;Blink on Activity   Connectors: (1) QSFP+ cage: MOLEX, P/N 75586-0010, or compatible.

10GBASE-T converged network adapter simplifies migration to 10 GbE, provides iSCSI, FCoE, Virtualization, and Flexible Port Partitioning. 10 Gigabit for the Broad Market The ALL0139-2-10G-TX is the latest innovation in Intel's leadership to drive 10 Gigabit Ethernet into the broader server market. This adapter hosts Intel's latest Ethernet silicon, the Intel Ethernet Controller X540, which is used by many OEMs as a single chip solution for LAN on Motherboard (LOM) to deliver 10 Gigabit Ethernet(10 GbE) on the latest server platforms. 10GBASE-T Simplifies the Transition to 10 GbE The ALL0139-2-10G-TX 10GBase-T works with existing networks today. It works with legacy Gigabit Ethernet (GbE) switches and Cat 6A cabling. Install the ALL0139-2-10G-TX 10GBase-T adapter into a server and the auto-negotiation between 1 GbE and 10GbE provides the necessary backwards compatibility that most customers require for a smooth transition and easy migration to 10 GbE. When time and budget allows, 10GBASE-T switches can be added any time to experience the full benefits of 10GbE. 10GBASE-T uses the copper twisted pair cables that are very familiar to IT professionals today. It is everything you know and love about 1000BASE-T. The knowledge, training and investment in BASE-T are preserved. 10GBASE-T is the easiest and most versatile 10 GbE and you can deploy it anywhere in your data center. Its flexible reach from 1 meter to 100 meters supports the latest network architectures including Top of Rack (ToR), Middle of Row (MoR), and End of Row (EoR). 10G Performance at Low Cost and Low Power The ALL0139-2-10G-TX 10GBase-T adapter is the lowest cost way to deploy 10 GbE in your data center today. The ALL0139-2-10G-TX uses low cost, Cat 6 and Cat 6A cabling. Chances are this cabling already exists in the data center. A way for Intel to reduce cost and power is to integrate components into a single- chip solution. Of course, integration is what Intel does best. With the new Intel X540 Controller, the MAC and the PHY are integrated into a single-chip solution. So, why is integration important? First, integration translates to lower power. A single-chip solution simply uses less power than two separate components. This means no more active heat sink and reduces the per-port power consumption. Second, integration also means lower cost per port. Manufacturing a single part costs less than two. When cabling is accounted for, cost efficiencies realized from a single part mean 10GBASE-T is the lowest cost media to deploy. With lower cost and power, 10GBASE-T is ready for broad deployment. 10GBASE-T is an option for every rack and tower server in the data center. The wait for a low cost 10 GbE copper solution to broadly deploy 10 GbE to all corners of the data center is over. The ALL0139-2-10G-TX 10GBase-T adapter  provides bandwidth-intensive applications with highly affordable 10 GbE network performance and cost-effective RJ-45 connectivity for distances up to 100 meters. Exciting New data Center usage Models More than simply a 10x increase in performance, with 10GbE there are exciting new usage models that are now possible, including Unified Networking (iSCSI, FCoE and LAN), Virtualization (VMDq and SR- IOV), and now, Flexible Port Partitioning (FPP). Flexible I/O Virtualization Virtualization changes the way server resources are deployed and managed by running multiple applications and operating systems independently on a single server. The ALL0139-2-10G-TX 10GBase-T adapter includes Intel Virtualization Technology for connectivity (Intel VT-c) to deliver I/O virtualization and Quality of Service (QoS) features designed directly into the Intel X540 controller on the adapter. Intel I/O virtualization advances network connectivity models used in today's servers to more efficient models by providing FPP, multiple Rx/Tx queues, and on-controller QoS functionality that can be used in both virtual and non-virtual server deployments. Flexible Port Partitioning (FPP) By taking advantage of the PCI-SIG SR-IOV specification, Intel Ethernet products enable FPP. With FPP, virtual controllers can be used by the Linux* host directly and/or assigned to virtual machines. FPP allows you to use the functionality of SR-IOV to assign up to 63 processes per port to virtual functions in Linux. This enables an administrator to partition their 10 GbE bandwidth across multiple processes, ensuring a QoS by giving each assigned process equal bandwidth. Network administrators may also rate-limit each of these services to control how much of the 10GbE pipe is available to each process. Unified Networking Unified Networking solutions on the ALL0139-2-10G-TX 10GBase-T adapter let you combine the traffic of multiple data center networks like LAN and SAN onto a single efficient network fabric. You now have the choice of NFS, iSCSI, or Fibre Channel over Ethernet (FCoE) to carry both network and storage traffic at speeds of up to 10 Gbps. The ALL0139-2-10G-TX 10GBase-T adapter combines support for all of these traffic types in one adapter at no additional cost and with no additional licensing fees for the adapter. Intel's Unified Networking solutions are enabled through a combination of standard Intel Ethernet products along with trusted network protocols integrated in the operating systems. Thus, Unified Networking is available on every Server either through LAN-on-Motherboard (LOM) implementation or via an add-in Network Interface Card (NIC). Intel has delivered high quality Ethernet products for over 30 years and our Unified Networking solutions are built on the original principles that made us successful in Ethernet: Open Architecture integrates networking with the server, enabling IT managers to reduce complexity and overhead while enabling a flexible and scalable data centre network. Intelligent offloads lower cost and power while delivering the application performance that customers expect. Proven Ethernet unified Networking is built on trusted Intel Ethernet technology, enabling customers to deploy FCoE or iSCSI while maintaining the quality of their traditional Ethernet networks. iSCSi Simplifies SAN Connectivity iSCSI uses Ethernet to carry storage traffic, extending the familiarity and simplicity of Ethernet to storage networking, without the need for SAN-specific adapters or switches. ALL0139-2-10G-TX is the easiest, most reliable, and most cost-effective way of connecting servers to iSCSI SANs. Open FCoE Consolidates LANs and Legacy SANs Intel's Open FCoE solution enables ALL0139-2-10G-TX (adapters and controllers) to support Fibre Channel payload encapsulated in Ethernet frames. There is no upgrade charge for Open FCoE on the adapter. Just as with iSCSI, now customers can easily connect to an FCoE network with Intel 10 GbE solutions. For the first time, Open-FCoE is now supported on 10GBASE-T. As 10GBASE-T switches come to market enabled with FCoE support, the ALL0139-2-10G-TX is ready when you're ready. This enables you to use cost-effective 10GBASE-T for all your converged networking needs. The Open- FCoE architecture uses a combination of FCoE initiators in Microsoft Windows*and Linux* operating systems and in the VMware* ESXi hypervisor to deliver high-performance FCoE solutions using standard 10 GbE Ethernet adapters. This approach enables IT managers to simplify the data center and standardize on a single adapter for LAN and SAN connectivity. The ALL0139-2-10G-TX is designed to fully offload the FCoE data path to deliver full-featured converged network adapter (CNA) functionality without compromising on power efficiency and interoperability Data Center Bridging (DCB) delivers Lossless Ethernet Conventional Ethernet does not guarantee successful data delivery, which is not acceptable for SAN traffic. Ethernet enhancements such as Data Center Bridging (DCB) overcome that limitation with technologies that guarantee lossless delivery, congestion notification, priority-based flow control, and priority groups. The combination of 10 GbE and unified networking helps organizations overcome connectivity challenges and simplify the data center infrastructure. 10 GbE provides a simple, well-understood fabric for virtualized data centers, one that helps reduce cost and complexity as the number of virtual machines continues to grow. Order Information: M/N Model DesDescription LREALL0139-2-10G-TX PCI PCI Express x8 Dual Copper Port 10GBase-T Server Adapter (Intel X540AT2 Based) PS: Above details are only for reference, if there is any change, no prior notice.

Kabel USB, C(St) => RJ45(St)_Netzwerkkarte,  2,0m, USB3.2 Type-C,  schwarz(Textil), Synergy 21, Kabeltyp USB3.2(geschirmt, PVC mit Baumwollgeflecht) Kategorie AWG28 Anschluss Seite A Typ C(Stecker) Anschluss Seite B RJ45(Stecker) Kabellänge 2 m Kabelfarbe Schwarz Besonderheit Kabel in Synergy21 Blisterverpackung Außendurchmesser 4,8mm Netzwerkgeschwindigkeit 10/100/1000Mbps

Description: ALLNET ALL0137-2-40G-QSFP+, Dual QSFP+ Fiber 40 Gigabit Ethernet PCI Express server adapter is designed for Servers and high-end appliances. ALL0137-2-40G-QSFP+ offer simple integration into any PCI Express X8 to 40Gigabit Networks. The performance is optimized so that system I/O is not the bottleneck in high-performance networking applications. ALLNET ALL0137-2-40G-QSFP+ is based on Intel XL710AM2 Ethernet controller with two fully integrated Gigabit Ethernet Media Access Control (MAC) and XLPPI Interface. In addition to managing MAC and PHY Ethernet layer functions, the controller manages PCI Express packet traffic across its transaction, link, and physical/logical layers. Using hardware acceleration, the controller offloads tasks from the host, such as TCP/UDP/IP checksum calculations and TCP segmentation. ALLNET ALL0137-2-40G-QSFP+ is the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers.   Key Features Performance Features: Support for jumbo frame up to 9.5KB Flow control support Priority Flow Control (draft IEEE 802.1Qbb) Enhanced Transmission Selection (draft IEEE802.1az) Statistics management and RMON 802.1q VLAN support DCB/DCB-X support Message Signal interrupts (MSI-X) Storage - Enabling competitive performance with native OS intelligent offload solutions, including NAS, iSCSI and FcoE   Host Interface: PCI Express X8 lanes Support PCI Express Base Specification 3.0 (8GT/sec)   LAN and Virtualization Features: Network Virtualization offloads for VXLAN and NVGRE Unified Networking Providing a single wire for LAN and storage: NAS (SMB, NFS) and SAN (iSCSI,FCoE) Virtual Bridging Support – VEPA/802.1Qbg, BPE/802.1Qbh Physical Functions – Up to 8 per port, up to 16 per device Support for 128 Virtual Device Queues (VMDq) per port Hardware Queue Pairs – Up to 1.5K (non-RDMA); up to 256K (RDMA) Virtualization - Alleviating hypervisor I/O bottlenecks by providing flow separation for Virtual Machines (VMs)   TCP/IP/L2 features: Receive Side Scaling (RSS) Large Send Offload (LSO) TCP/UDP/IP/SCTP Checksum Offload IPV4, IPV6 Technical Details: QSFP+ 40Gigabit Ethernet Technical Specifications Adapters: QSFP+ (Quad Small Formfactor Pluggable) supports: XLPPI interfaces supports 40GBase-R PCS and 40 Gigabit PMA in order to connect with QSFP+ to 40GBase-SR4 / 40GBase-LR4 / 40G Direct Attach Cable IEEE Standard /Network topology: with 40GBase-SR4 QSFP+ Fiber 40Gigabit Ethernet, 40GBASE-SR4 (850nm LAN PHY). IEEE Standard /Network topology: with 40GBase-LR4 QSFP+ Fiber 40Gigabit Ethernet, 40GBASE-LR4 (1310nm LAN PHY) Operating Systems Support Operating system support: Windows Linux General Technical Specifications Interface Standard: PCI-Express Base Specification Revision 3.0 (8 GT/sec) Board Size: 165mm X 69mm(6.496 X 2.717) PCB thickness is 0.062 inch PCI Express Card Type: X8 Lane PCI Express Voltage +12V +- 8% PCI Connector: X8 Lane Controller: Intel XL710AM2 Holder: Metal Bracket Weight: 170 gr (5.997 oz) Power Consumption: 2.880 W Operating Humidity: 0%–90%, non-condensing Operating Temperature: 0°C – 45°C (32°F – 113°F) Storage: -40°C–65°C (-40°F–149°F) EMC Certifications: FCC PART 15B EN 55022: 2010 EN 55024: 2010 EN 61000-3-2:2014 EN 61000-3-3:2013 LEDs LEDs: Link 10G: Green Link : 40GYellow Act: Blue;Blink on Activity Connectors: (2) QSFP+ cage: MOLEX, P/N 75586-0010, or compatible.
