Router - Enterprise

AS5916-54XM, Additional one year hardware warranty, return to factory. Maximum of 5 years hardware warranty allowed per product, 3 years hardware warranty already included with product, a maximum of two additional years of hardware warranty can be purchased with this SKU. Fan and PSU modules are excluded.

Fan Module, front-to-rear airflow, 1 Year Warranty (for COR580/AS9926-24DB).

AS5915-18X,Additional one year hardware warranty, return to factory. Maximum of 5 years hardware warranty allowed per product, 3 years hardware warranty already included with product, a maximum of two additional years of hardware warranty can be purchased with this SKU. Fan and PSU modules are excluded.

AS7515-24X, 4x40/100G QSFP28, 20x1/10/25G SFP28; 2x300W 1+1 Load-Sharing Redundant DC 48V PSU, Broadcom Qumran-2U, 360Gbps; Intel® ATOM® Processor C3508 4-Core CPU; GNSS Antenna Connection, Modular Fantray Left-to-Right airflow, 2 front rack mounting ears, 3-Year-Warranty Included

1000BASE-LX SFP (Single-mode 10km/1310nm, LC)

AS7316-26XB, 2 x 100G QSFP28 + 8 x 25G SFP28 + 16 x 10G SFP+ ports, Broadcom Qumran-AX 300Gbps ASIC, Quad-core Intel Xeon® D1519 CPU, dual hot-swappable AC PSUs and 4+1 Fan Modules with Front-to-Rear airflow, 2 front rack mounting ears, 3 years Hardware Warranty

AS5915-18X, 6 x 10G SFP+ + 8 x 1G SFP + 4 x 1G RJ45 ports, Broadcom Qumran-UX 128Gbps ASIC, Dual-core Intel Atom C3308 CPU, dual hot-swappable AC PSUs and 3+1 Fan Modules with Left-to-Right airflow, 2 front rack mounting ears, 3 years Hardware Warranty

AS5915-18X, 6 x 10G SFP+ + 8 x 1G SFP + 4 x 1G RJ45 ports, Broadcom Qumran-UX 128Gbps ASIC, Dual-core Intel Atom C3308 CPU, dual hot-swappable DC PSUs and 3+1 Fan Modules with Left-to-Right airflow, 2 front rack mounting ears, 3 years Hardware Warranty

AS5916-54XM, 48 x 10G SFP+ + 6 x 100G QSFP28 ports with MACSEC, Broadcom Qumran-MX 800Gbps ASIC, Quad-core Intel Xeon® D1518 CPU, dual hot-swappable 650W 48VDC PSUs and 4+1 Fan Modules with Rear-to-Front airflow, rack mount kit (Front and back), 3 years Hardware Warranty

Fan Module, front-to-rear airflow, 1 Year Warranty (for AGR100/AS5912-54X, AGR110/AS5916-54XL, AGR120/AS5916-54XM, AGR130/AS5916-54XKS).

Fan Module, rear-to-front airflow, 1 Year Warranty (for AGR100/AS5912-54X, AGR110/AS5916-54XL, AGR120/AS5916-54XM, AGR130/AS5916-54XKS).

Fan Module, front-to-rear airflow, 1 Year Warranty (for CSR320/AS7316-26XB).

1300W AC Power Supply (ACBEL), front-to-rear airflow, 1 Year Warranty (for DCS510/AS9716-32D, COR580/AS9926-24DB, AGR400/AS7946-30XB, AGR420/AS7946-74XKSB). Inlet Connector: IEC 60320 C16.

48VDC Power cord Positronic PLA03F7000/AA to 3 x Ring terminal, 12AWG (4mm²), 3050 mm, -25-85°C, PVC, Colors: Black, Red, Yellow/Green. Certifications: UL. (for AGR100/AS5912-54X, AGR120/AS5916-54XM, AS7312-54XS, DCS203/AS7326-56X, DCS501/AS7712-32X, DCS204/AS7726-32X).

600W AC Power Supply (LiteOn), front-to-rear airflow, 1 Year Warranty (for CSR440/AS7535-28XB). Inlet Connector: IEC 60320 C16.

AS9926-24DB, Additional one year hardware warranty, return to factory. Maximum of 5 years hardware warranty allowed per product, 3 years hardware warranty already included with product, a maximum of two additional years of hardware warranty can be purchased with this SKU. Fan and PSU modules are excluded.

1300W 48VDC Power Supply (ACBEL), rear-to-front airflow, 1 Year Warranty (for COR580/AS9926-24DB, AGR400/AS7946-30XB, AGR420/AS7946-74XKSB. Inlet Connector: Screw Terminals. Power cable is NOT included.

AS7946-74XKSB, 2x100G Hi-Powered(16.5W) QSFP-DD, 8x40/100G QSFP28(5W), 64x1/10/25G SFP28; 2x1,300W 1+1 Load-Sharing Redundant AC PSU, Broadcom Qumran-2C, 2.4Tbps; Intel® Xeon® Processor D-1548 8-Core, 4+1 Modular FantrayFront-to-Rear airflow, 1 pair of rack mount kit, ONIE Software Installer, 3-Year-Warranty Included

ONSITE,9100,MOD; 21xE1, 120 OHM, FB

AS9926-24DB, 24 x 400G QSFP-DD ports, Broadcom Ramon 9.8Tbps ASIC, 8-core Intel Xeon® D1548 CPU, dual hot-swappable AC PSUs and 4+1 Fan Modules with Front-to-Rear airflow, rack mount kit (Front and back), 3 years Hardware Warranty

850W AC Power Supply (3Y), front-to-rear airflow, 1 Year Warranty (for AGR110/AS5916-54XL, AGR130/AS5916-54XKS, DCS500/AS7816-64X). Inlet Connector: IEC 60320 C14.

AS5912-54X, 48 x 10G SFP+ + 6 x 100G QSFP28 ports, Broadcom Qumran-MX 800Gbps ASIC, Quad-core Intel Atom C2538 CPU, dual hot-swappable 650W 48VDC PSUs and 4+1 Fan Modules with Front-to-Rear airflow, rack mount kit (Front and back), 3 years Hardware Warranty

AS5912-54X, 48 x 10G SFP+ + 6 x 100G QSFP28 ports, Broadcom Qumran-MX 800Gbps ASIC, Quad-core Intel Atom C2538 CPU, dual hot-swappable 650W AC PSUs and 4+1 Fan Modules with Rear-to-Front airflow, rack mount kit (Front and back), 3 years Hardware Warranty

AS7315-30X,Additional one year hardware warranty, return to factory. Maximum of 5 years hardware warranty allowed per product, 3 years hardware warranty already included with product, a maximum of two additional years of hardware warranty can be purchased with this SKU. Fan and PSU modules are excluded.
